Reed Manufacturing R7200-NIST LED Stroboscope With Calibration Certificate

The Monarch 6231-010 DBL battery-operated stroboscope has a 12-array LED light source, internal and external trigger modes, a 30 to 500,000 flashes/revolutions-per-minute (FPM/RPM) range, and a continuous duty cycle to provide stop-motion inspection and speed measurement. It is designed for motion analysis, preventive maintenance, printing inspection, and speed measurement of repetitive motion. The 12-array LED light source has an adjustable flash duration up to 14 degrees or 3000 microseconds and a light output of 3000 lux. The flash rate range of 30 to 500,000 FPM/RPM has an accuracy of 0.002% of setting, or + or - 1 least-significant digit/0.01 FPM. A NIST Certificate of Calibration ensures accuracy. Tachometer mode, available for use while the stroboscope is in external mode, has a measuring range of 5 to 200,000 rpm and an accuracy of + or - 0.01% or 0.1 rpm (remote sensor not included). The internal NiMH rechargeable battery has a typical life-span of 8 to 10 hours at 1800 FPM and includes a universal 115/230V AC recharger. An integrated 1/4 - 20 UNF (Unified Fine) thread enables the stroboscope to be mounted on a tripod for long-term use. The stroboscope includes a universal 115/230V AC charger with interchangeable wall plugs, a NIST Certificate of Calibration, and instructions. /860gH is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. They are used in industries such as manufacturing, entertainment, high-speed printing, wood and metal turning, and in education and research settings. Stroboscopes have a flashing light (strobe) that, when directed at a moving object, makes the object appear to be stopped or moving in slow motion. This enables the operator to evaluate machine performance without stopping the machine. The strobe is triggered either internally, which allows the operator to manually adjust the flash rate, or externally and automatically by a peripheral sensor. Multiply-by-2 (2/4 or 2X) and divide-by-2 (1/2) functionality enables the operator to verify the actual revolutions per minute (RPM) and to distinguish true RPM from harmonics. Phase shift adjusts the flash delay in degrees of a full rotation, and time delay adjusts the flash delay in seconds or fractions of a second. Input and output features enable the operator to use peripheral sensors to trigger flash rates, to perform tachometer operations, or to daisy-chain stroboscopes. 115/230 Universal charger with interchangeable wall plugs NIST Certificate Instructions 30 to 500,000 flashes/revolutions -per-minute (FPM/RPM) range and adjustable flash duration provides crisp images in high-speed applications 12-array LED light source provides bright light output, long bulb life, and long battery life Continuous duty cycle for the life of the battery (8 to 10 hours, typical)
